MOTOTRBO XPR Portable Basic Service Manual

The Motorola 6880309T30 MOTOTRBO Portable Basic Service Manual is a technical service and maintenance reference for select Motorola MOTOTRBO XPR 6000 Series portable two-way radios.

Designed for radio technicians, service centers, self-maintained customers, and Motorola radio dealers, this manual provides the technical information needed to perform Level 1 and Level 2 maintenance procedures on supported portable radios.

The manual covers maintenance through the board-replacement level and provides technicians with information for radio testing, troubleshooting, disassembly, reassembly, parts identification, and servicing.

The 6880309T30 manual covers multiple display and non-display XPR portable radio configurations, including models with and without GPS.

Key Features

• MOTOTRBO portable radio Basic Service Manual

• Technical service and maintenance documentation

• Designed for select XPR 6000 Series portable radios

• Covers Level 1 maintenance procedures

• Covers Level 2 maintenance procedures

• Supports maintenance through board-replacement level

• Includes radio troubleshooting information

• Includes transceiver performance testing procedures

• Includes disassembly and reassembly procedures

• Includes exploded mechanical views

• Includes replacement parts information

• Includes service aids and test equipment information

• Includes accessory information

• Includes radio model and frequency-band information

• Includes safety and RF exposure information

• Includes replacement parts ordering information

• Includes service-center information

• Intended for technicians, dealers, service centers, and self-maintained radio fleets

• Motorola document number: 6880309T30

Supported Radio Models

The 6880309T30 Basic Service Manual covers the following Motorola MOTOTRBO portable radio families:

• Motorola XPR 6100

• Motorola XPR 6300

• Motorola XPR 6350

• Motorola XPR 6500

• Motorola XPR 6550

The manual identifies these configurations as:

XPR 6550 – Display Portable with GPS

XPR 6500 – Display Portable

XPR 6350 – Non-Display Portable with GPS

XPR 6300 – Non-Display Portable

XPR 6100 – Non-Display Portable

Service and Maintenance Coverage

The 6880309T30 is a Basic Service Manual, providing information for Level 1 and Level 2 maintenance.

Motorola describes this level of service as extending to the:

Board Replacement Level

This type of servicing is commonly performed by:

• Local radio service centers

• Motorola radio dealers

• Fleet maintenance departments

• Self-maintained customers

• Professional radio technicians

• Communications equipment distributors

For troubleshooting or repair beyond the basic service level, additional detailed service information and appropriate technical equipment may be required.

Manual Contents

The 6880309T30 provides technical information covering areas such as:

• Product safety information

• RF exposure compliance

• Radio model information

• Radio specifications

• Test equipment

• Service aids

• Transceiver performance testing

• Radio alignment information

• Troubleshooting

• Disassembly procedures

• Reassembly procedures

• Mechanical parts information

• Exploded radio views

• Accessories

• Replacement parts ordering

• Service information

• Technical terminology and glossary information

The exact contents can vary according to the revision of the manual.

XPR Display Radios

The manual provides service information for the display-equipped:

• XPR 6500

• XPR 6550

The XPR 6550 configuration includes GPS functionality, while the XPR 6500 is identified as the corresponding display model without GPS.

XPR Non-Display Radios

The manual also provides service information for the non-display:

• XPR 6100

• XPR 6300

• XPR 6350

The XPR 6350 is identified as the GPS-equipped non-display configuration.

Basic vs. Detailed Service Manual

The 6880309T30 is the:

MOTOTRBO Portable Basic Service Manual

Motorola also produced a separate:

6880309T31 – MOTOTRBO Portable Detailed Service Manual

Customers should select the appropriate documentation according to the level of technical servicing they intend to perform.

The Basic Service Manual is intended primarily for Level 1 and Level 2 maintenance through board replacement.

Important

The 6880309T30 is a technical service manual, not a standard radio user guide.

It is intended primarily for technicians and organizations servicing compatible Motorola MOTOTRBO portable radios.

It should not be confused with:

6880309T31 – MOTOTRBO Portable Detailed Service Manual

The manual does not include a portable radio, replacement parts, programming cable, test equipment, or other radio accessories.

Compatibility and technical information may vary according to the specific revision of the manual and radio hardware.

Specifications

Manufacturer: Motorola Solutions
Part / Document Number: 6880309T30
Product Type: Technical Service Manual
Manual Type: Basic Service Manual
Product Family: MOTOTRBO
Radio Series: XPR 6000 Series
Service Level: Level 1 and Level 2
Service Scope: Through Board Replacement Level
Supported Models: XPR 6100, XPR 6300, XPR 6350, XPR 6500, XPR 6550
Intended Users: Radio Technicians, Service Centers, Dealers, Distributors and Self-Maintained Customers
Radio Included: No
Application: MOTOTRBO Portable Radio Service and Maintenance
